Mimaki UCJV330-130 Series - 54 Inch UV-LED Printer

No customer reviews Write a review

Sku:

Retail price:

SW Wholesale Price:

SignWarehouse Pro Icon

Sale price:

Get $839.85 back with SignWarehouse PRO

Call Now Buy Online
Add to Wishlist

Note:
Orders exceeding the stock on hand amount are processed as special orders, which require additional processing and shipping time and are not eligible for return.

Campaign rebates:
When purchasing this product between the displayed dates, you will be issued a partial rebate amount to your account each month until the total amount has been issued.

Overview

Specs

Applications

Video

Professional installation and training required. Contact our Sales Department for all-inclusive pricing. (903)-462-7700

The new UCJV330 Series integrated printer/cutter offers extremely versatile UV-LED roll-to-roll inkjet printing with significantly improved productivity and image quality for sign graphics applications. The Mimaki UCJV330 Series enables users to provide their customers with impressive turnaround times and produce more jobs with increased efficiency. In addition, the high speeds achievable with this technology do not compromise the image quality. This is thanks to Mimaki’s newly developed patent-pending ink ejection technology that reduces color irregularities in high density areas even in high-speed output mode.

Features:

  • Available in 54 or 64 inch size
  • 2 in-line on-demand piezo printheads
  • Significantly improved image quality and productivity
  • Mimaki’s UV printing technology achieves high image quality even at high speeds
  • Clear ink that expands the design potential makes it possible to produce high value-added printed deliverables
  • Furthermore, 2.5D print and watermark print functions have been added
  • Support for up to 5-layer printing expands the range of applications and the added value of deliverables
  • New ink technology was created to allow more stretchability for UV-printed vehicle wraps with the added benefit of not having to wait for outgassing before lamination
  • UV-curable ink that does not require drying time after printing, and a post-print cut function
  • Instantly cured prints for shorter turnarounds and additional cost savings
  • “PICT” supports customers in improving the efficiency of their printing operations and production management by enabling them to remotely manage performance of their printers from a PC or mobile device
  • Nozzle Check Unit (NCU), automatically monitors printhead performance and detects clogged nozzles
  • The Nozzle Recovery System (NRS), automatically substitutes unproductive nozzles, avoiding unnecessary downtime and poor image quality
  • USB/Ethernet connectivity
  • Maximum print area: 53.5 inches
  • Maximum media width: 53.9 inches

Mimaki UCJV330 Series Specifications Sheet

Mimaki UCJV330 Series Brochure

Mimaki UCJV330-130 Specifications
Print HeadTwo In-line On-demand Piezo Heads
Maximum Print Resolution1800 dpi
Maximum Print Area53.5 in (1360 mm)
Maximum Media Width53.9 in (1370 mm)
Maximum Media Thickness0.04 in (1 mm)
Maximum Media Weight99.2 lbs. (45 kg)
Ink typeLUS-170, LUS-200
InterfaceEthernet 1000 BASE-T (recommended), USB2.0 Hi-Speed
Power SupplySingle phase AC100-120V±10% /12A or
Single phase AC200-240V±10% /6A
50/60Hz±1Hz
Power ConsumptionMax. 1,440W or less x1 / 800W (Continuous operation) / 4.5W or less (Sleep mode)
Operational EnvironmentTemperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing)
Dimensions103.9 in x 31.5 in x 58.3 in (2,640 mm x 800 mm x 1,480 mm)
Weight478.4 lbs. (217 kg)
Shipping DimensionsTBD
Shipping WeightTBD
Shipping Crate/PalletShipped in a crate on a pallet
Safety StandardIEC 62368-1 Standard ETL
CB, CE (EMC Directive, Low Voltage Directive, Machinery Directive, RoHS Directive)
REACH, VCCI class A, FCC class A
KC, RCM, UKCA, EnergyStar
WarrantyOne Year Trouble-free Warranty
SupportOne year complimentary Gold Support

Applications:

  • Wall and floor graphics
  • Architectural graphics
  • Posters & Paper
  • PET Film
  • Stickers & labels
  • Interior/exterior signage
  • Pop-ups & much more
